LX-type electric single girder suspension crane 8ton Material Handling
| Parameter | Specification |
| Type | Electric Suspension Crane |
| Capacity (Lifting Load) | 5 ton (5000 kg) |
| Span | 9m |
| Lifting Height | Customizable (e.g., 6m, 9m, etc.) |
| Lifting Speed | 5/0.8m/min (standard) |
| Trolley Travel Speed | 20/5 m/min (VFD) |
| Bridge Travel Speed | 20/5 m/min (VFD) |
| Power Supply | 3-phase, 380V/50Hz (or as required) |
| Control Method | Pendant control / Radio |
| Duty Class | FEM 1Am / ISO M3 (Light-Medium Duty) |
| Protection Level | IP55 (Dust & Waterproof) |
| Safety Features | Overload limiter switches, emergency stop |
1. Good economy:
Compared with bridge cranes of the same tonnage, the equipment cost of suspension cranes is usually lower.
The installation cost may also be lower because it utilizes the existing plant structure (the structural strength must be confirmed to be sufficient) and reduces the ground foundation engineering.
The operation and maintenance costs are also relatively economical.
2. Modular design and strong adaptability:
The main beam length and track span can be customized according to the specific size of the plant.
The selection of electric hoists (such as running speed, lifting height, and working level) also has a certain flexibility.
It has good adaptability to the plant, especially suitable for renovation projects or places with limited space.
3. Main structure:
Main beam: Usually a box beam structure is adopted, which has good strength and rigidity.
End beam: Connected to both ends of the main beam, equipped with walking wheels and drive mechanisms, responsible for running along the track.
Electric hoist: It is the core lifting mechanism, suspended on the trolley track under the main beam, and can run along the main beam. Common domestic hoist brands such as CD1/MD1, imported brands such as Demag, Kone, and Anbo also have corresponding products.
Running track: Usually I-beam (such as I16, I20, I22, I25, etc., the specific size is determined by the lifting weight, span and working level), fixed on the lower chord or support beam of the factory building frame.
Electrical control system: Including power supply introduction, motor control of each mechanism, protection device (limit switch, overload protection, etc.) and operator (flashlight or remote control).
4. Safety device:
Usually equipped with necessary safety devices, such as:
Lifting limit switch: Prevent the hook from hitting the top.
Cart/trolley travel limit switch: Prevent collision at the end of the track.
Overload protection: (depending on the configuration) Prevent overload operation.
Emergency stop button: On the operator.
Buffer: At both ends of the end beam, absorb collision energy.
Product Tags:
|
|
LX-type Electric Single Girder Suspension Crane 8ton Material Handling Images
|
